In general people don't like to wait. And no matter how fast we make our application there will always be something that takes time to process. But in many cases, if the user is informed, they will be more patient.

Fortunately, CAPP Agile Learning is pretty fast and there is little waiting time. But sometimes transitioning between pages can take a brief moment, ie. due to slow internet or a large request to the server.

So we can't prevent loading time but we can make it less boring. Show something awesome instead of a simple spinner or loading message. At least tickle the user's senses a bit while waiting. The first thing that came to mind was the isometric shape in our logo, consisting of a cube within a cube (or three times the letter "L" surrounding a cube). Perfect for our loading indicator:

In this post I will explain and demonstrate how we recreated and animated our logo, and how to use it as a loading indicator in Ember.js.

## Isometric cubes

The biggest challenge is recreating our logo using HTML and CSS. There are several ways to accomplish this but we are using the CSS transform property to create the isometric faux-3D effect (sometimes refered to as 2.5D).

We need two cubes, but lets start with the first one. Create a container with three child elements for the visible cube faces (top, left and right):

``````<div class="cube">
<span class="face top"></span>
<span class="face left"></span>
<span class="face right"></span>
</div>
``````

Now we add the styling. Give the faces a background color and make sure they are square. Next we apply the math to create the isometric effect using the `transform` property. This property can take a list of transform functions but in the examples below we will only be using `rotate`, `skew`, `scale` and `translate`. Also note we use transform-origin which gives us control over the origin for the transformations. The CSS looks like this:

``````.cube {
position: absolute;
top: 100px;
left: 100px;
}

.face {
transform-origin: 0 0;
position: absolute;
height: 100px;
width: 100px;
}

.top {
background: #f5f5f5;
transform:
rotate(210deg)
skewX(-30deg)
scaleY(0.864));
}

.left {
background: #ccc;
transform:
rotate(90deg)
skewX(-30deg)
scaleY(0.864));
}

.right {
background: #e0e0e0;
transform:
rotate(-30deg)
skewX(-30deg)
scaleY(0.864));
}
``````

Note: Don't forget to add vendor prefixes for the `transform*` properties if you want cross-browser support. In the demos I use SCSS and the Bourbon mixin library so I don't have to worry about these prefixes.

Check out the demo. I also created a demo of an alternative technique.
Both techniques are shown in the demo below.

Now we need a second cube so we can recreate our logo. Duplicate the cube and wrap them in a container:

``````<div class="logo">
<div class="cube">
<span></span>
<span></span>
<span></span>
</div>
<div class="cube">
<span></span>
<span></span>
<span></span>
</div>
</div>
``````

Rotate the second cube 180 degrees and scale it to half its size:

``````.cube:nth-child(2) {
transform: rotate(180deg) scale(0.5);
}
``````

Thats about it, see the result below. I also added some extra styling to render the cube as a wireframe like we have in our logo.

To make the loading indicator complete we will add some animation. This can be done fairly easily with CSS by using @keyframes and animation. The `@keyframes` rule gives us control over the intermediate steps in an animation by defining keyframes (or waypoints). Each keyframe describes how the animated element should render at a given time during the animation sequence. The `animation` property lets you configure the timing and duration of the animation, as well as other details of how the animation sequence should progress.

For our loading indicator we want the cubes faces to shift between 3 colors by animating the background color. To do this we create an animation named "color-shift" and add 4 keyframes: start, finish and 2 in between:

``````@keyframes color-shift {
0%, 100% {
background: #ccc;
}
33% {
background: #e0e0e0;
}
66% {
background: #f5f5f5;
}
}
``````

Now we can apply the animation to the cubes' faces. We configure the animation by setting its name (color-shift), duration (1.2s) and iteration count (infinite). But we don't want the cube's faces to get the same color on each keyframe. So we use `animation-delay` on the 2nd and 3rd face to delay the animation for these elements:

``````.cube span {
animation: color-shift 1.2s infinite;
}
.cube span:nth-child(2) {
animation-delay: -0.8s;
}
.cube span:nth-child(3) {
animation-delay: -0.4s;
}
``````

Note: Don't forget to add vendor prefixes for `@keyframes` and `animation*` if you want cross-browser support.

Like the animations but think all the isometric projection math is too much fuzz? Don't worry, you can create the same effect with inline SVG. In fact, we are now using SVG for our loading indicator in CAPP Agile Learning.

The demo below shows the HTML and the SVG aproach, both powered by the same CSS animation! The only difference with SVG is we have to animate the path's "fill" attribute instead of background color.

The only thing left to do was getting our loading indicator to show up between page transitions in Ember.js. Fortunately Ember provides loading substates that allows you to do just that. Basicly the only thing we had to do is create a top-level template called `loading` and Ember takes care of the rest:

``````<script type="text/x-handlebars" data-template-name="loading">
